Fraunhofer IOF presented new systems at the LASER World of PHOTONICS 2019

Our Fair Highlights 2019

(List of all exhibits below)





Additive manufacturing of lightweight mirrors and systems



Telescopes for space applications are based on precise, mass-reduced and stable arrangements of several mirrors. Additive manufacturing processes offer new concepts for the production of metal optics that can overcome the specific limitations of conventional manufacturing technologies. Fraunhofer IOF presents a lightweight mirror system manufactured in such way, whose internal and external housing structures have been produced by selective laser melting (SLM) of aluminium-silicon material. The mass reduction of a single mirror component reaches up to 64 %, using an internal structure which is not manufacturable by conventional techniques.

Additively manufactured lightweight mirror made of AlSi alloy after final  polishing step.
© Fraunhofer IOF
Additively manufactured lightweight mirror made of AlSi alloy after final polishing step.

Optical quantum technologies



The Fraunhofer IOF is a pioneer in applied research on photonic quantum technologies. For the first time, developments in the field of quantum imaging will be presented at this year's LASER World of PHOTONICS. It is a quantum photonically based imaging system. By using high-power sources of entangled photons, such as those developed at the Fraunhofer IOF, future imaging systems based on quantum technologies can become even more compact, e.g. for applications in biology and medical technology.

Quantum Optical Imaging System – A robust monocrystal setup enables the examination of an object in the ultraviolet (UV) or infrared (IR) spectral range.
© Fraunhofer IOF
Quantum Optical Imaging System – A robust monocrystal setup enables the examination of an object in the ultraviolet (UV) or infrared (IR) spectral range.

Fast adaptive focusing mirrors for materials processing



The fast adaptation of the laser focus in materials processing requires adaptive optics with fast response times. In order to enable the user to easily integrate and upgrade existing systems, Fraunhofer IOF presents a focusing mirror that is designed as a 90° deflecting mirror and achieves a reaction time of a few milliseconds. On display will be a version for laser cutting and laser welding, as well as a further version with integrated plane field correction for applications in laser structuring systems. The technology was developed within the BMBF project »Piezo-driven beam shaping for highly dynamic laser materials processing in 3D space«, which is part of the smart³ innovation network.

Adaptive focusing mirrors with ultra-short reaction times. Left: Version with integrated plane field correction for applications in laser structuring systems. Right: Version for laser cutting/laser welding.
© Fraunhofer IOF
Adaptive focusing mirrors with ultra-short reaction times. Left: Version with integrated plane field correction for applications in laser structuring systems. Right: Version for laser cutting/laser welding.

Ultra-compact multispectral camera



The ultra-compact multispectral camera system developed at the Fraunhofer IOF records twelve individual spectral and spatially resolved channels simultaneously. The innovative concept is based on the integration of a microoptical multi-aperture objective and a customized monolithic filter-array, which comprises 4x3 expanded filter tiles. The required new filter concept was realized by a combination of gray-scale lithography and dry etching processes for the lateral structuring of the filter design and thus the individualization of the parallelized imaging channels. Possible applications are e.g. precision farming, security and surveillance, biomedical engineering, recycling or industrial sorting.

Very high spatial resolution and real-time detection of 12 spectral channels in a very compact design - This is made possible by the ultra-compact multispectral camera of the Fraunhofer IOF.
© Fraunhofer IOF
Very high spatial resolution and real-time detection of 12 spectral channels in a very compact design - This is made possible by the ultra-compact multispectral camera of the Fraunhofer IOF.

Events and lectures



June 25, 2019

Tour for the press

  • Time: 12:30 to 14:00 pm /
    Tuesday, June 25, 2019

  • Venue: Fraunhofer joint booth,
  • Hall A2, Booth 431
    (Part I of the tour)
  • Hall B3, Booth 335
    (Part II of the tour)




Lecture / June 25, 2019

OptoNet e.V.:
[fo+] Freeform Optics Plus – The Next Level

  • Speakers: OptoNet e.V.: Lutz Reichmann, Dr. Andreas Beutler, Prof. Herbert Gross, Sven R. Kiontke

  • Time: 13:20 to 14:40 pm /
    Tuesday, June 25, 2019

  • Venue: Hall B3, Booth B3.361









Lecture / June 26, 2019

Quantum-enhanced Imaging

  • Speaker: Markus Gräfe

  • Time: 16:00 to 16:20 pm /
    Wednesday, June 26, 2019


  • Hall B3, Booth B3.361



Application Panel / June 24, 2019

CW Diode Pumped Solid State Lasers and Fiber Lasers

  • Time: 14:40 to 16:35 pm /
    Monday, June 24, 2019

  • Venue: Forum in Hall B3


Application Panel / June 25, 2019

Ultrashort Pulse Lasers and Beam Delivery

  • Time: 15:00 to 17:00 pm /
    Tuesday, June 25, 2019

  • Venue: Forum in Hall B3


Application Panel / June 26, 2019

Optical Quantum
Technologies

  • Part I - Sensing and Computing
  • Time: 13:00 to 15:00 pm /
    Wednesday, June 26, 2019

  • Part II - Imaging and Communication
  • Time: 15:00 to 17:20 pm /
    Wednesday, June 26, 2019



  • Venue: Forum in Hall B3

Overview of the Fraunhofer IOF exhibits

- Optical systems - Microoptical systems - Fiber laser technologies - Quantum technologies -

Optical systems

Microoptical systems

Diffractive optical elements and wafer-level optical systems



Fiber laser technologies

Quantum technologies

Schedule

LASER World of PHOTONICS


Stand number / Hall:

Fraunhofer joint booth (335) in Hall B3

Opening hours:

Monday, June 24, 2019 09:00 – 17:00 Uhr
Tuesday, June 25, 2019 09:00 – 18:00 Uhr
Wednesday, June 26, 2019 09:00 – 18:00 Uhr
Thursday, June 27, 2019 09:00 – 16:00 Uhr



Venue:
Exhibition Munich

Entrance West
Am Messesee
81829 Munich, Germany
Car Park West
Paul-Henri-Spaak-Str. 6
81829 Munich, Germany
